TEC1-12706

Cooler Peltier Module TEC1-12706 – Thermoelectric, Thermomodule 12V 6A

$11.00
Tax included

Peltier Module TEC1-12706 - max 91,2W - Thermoelectric - cooler - 40x40x3,9; 53,3W; 12V; max 6A. Cooling components are used for example in portable car fridges, wine and beer coolers, CPU. Thermomodule, heat pump, to heating, keep the temperature, Generator, transform electricity into temperature. Liquid Component Cooling, Food and Beverage Refrigeration, Commercial Portable Cooling, Medical

Volume discounts

Quantity Unit discount You Save
5 $0.28 $1.40
10 $0.55 $5.50
Quantity

Thermoelectric Cooler (Peltier Module) - TEC1-12706


Size: 40x40x3.9mm (WxDxH)

Peltier Modules are suitable for the following applications in portable car fridges, coolers, wine and beer coolers.

More information for example on Peltier.pl


It is common in mini tourist fridges for 12V/230V.

Power max   91,2W
Refrigeration power Qcmax   53,3W
Current   4,5A (max 6A)
Voltage   12V (max 15,4V)
Resistance  1,9 - 2,2 Ohm
Length of cables   15cm
Delta Tmax   59°C
Temperature min.  -135°C
 Durability (h)   200 000



Using more cells "one on another" ("hot" side together with "cold" of another cell) it increases efficiency of module, with minimum energy loss.

We offer: TEC1-12706

Modules are protected with silicon sealed. In additional, you can use THERMALLY CONDUCTIVE on radiator.
